3 axle Curtain Side Trailer

Curtain Side Trailer

The front and back of the Curtain Side Trailer are made of corrugated railings to prevent the cargo from tipping forward or moving backward, increasing safety during transportation. When we need to load or unload, we only need to slide the side curtain forward or backward to have enough space for loading. Because the space is large enough, many people can work together during loading and unloading, and forklifts or cranes can be used for loading and unloading at the same time.

The trailer is made of high-strength steel, with channel steel and I-beams in places where the trailer is prone to damage or breakage, making the trailer more sturdy and durable and able to cope with different road conditions.

High-strength knife scraping cloth, 950g/square meter, thickness 0.75mm, reinforcing rib is 2 tons of special webbing, performance, waterproof, sunscreen, anti-aging, anti-UV, fire retardant, opaque. Commitment: ten years of no fading, no peeling, no cracking, no elegance.

Specification：

Overall dimension：12500mm * 2500mm *4000mm

Loading capacity: 60 ton

Axles：3 axles

Suspension：Heavy duty mechanical spring suspension

Tire：12 units

Landing gear：28 T

Brake system: WABCO

Others: 600mm high side walls on both sides

Shipping Method，Before leaving the factory, the trailers are sprayed with wax and then covered with tarpaulin. Three trailers in a group can save more shipping costs. The trailers can also be loaded into containers. Each 40 high container or 45 high container can accommodate two trailers.
